Product Description:
Optional motors Ordinary motor Explosion-proof motor Variable frequency motor Variable frequency explosion-proof motor.The pulp pump has a rear-opening structure. It is not necessary to disassemble the pipeline for maintenance. The inlet and outlet flanges of the pump are designed according to the pressure of 1.6MPa. The main parts are pump housing, front protective liner, impeller (three blades or six blades), rear protective liner, rear protective liner, rear pump cover, suspension, pump shaft, front and rear bearing covers.
2. Based on imported pulp pump products, our company has improved the hydraulic model to increase the pump's passing capacity and the concentration of the pulp delivered. The impeller of this series of pumps is fully open, without blockage, no leakage at the sealing part, wide flow channel, strong passing capacity, can pass through particles with a diameter of 20-80mm, fiber length of 100-400mm, and convey various slurries with a slurry concentration of less than 6%. It has a wide range of applications and is about 10-20% more efficient than the old pulp pump products.
Product Features:
●Non-clogging performance
●Good wear resistance
●Higher head
●Low noise operation
●Good sealing
●Easy to maintain
●Wide applicability
Technical Parameters:
| Pump type | Flow | Head | Speed | Power | Rate | Impeller DN |
| m3/h | L/S | M | r/min | KW | (%) | mm |
| HT80 - 265 | | 180 | 50 | 53.9 | 2900 | 55 | 60 | 265 |
| A | 160 | 44.4 | 51.5 | 45 | 60 | 255 |
| B | 154 | 42.8 | 44.9 | 37 | 60 | 245 |
| C | 140 | 38.8 | 40.8 | 37 | 60 | 235 |
| D | 130 | 36.2 | 36.7 | 30 | 60 | 225 |
| E | 120 | 33.4 | 32.7 | 22 | 60 | 215 |
| | 70 | 19.4 | 15 | 1450 | 5.5 | 60 | 265 |
| A | 60 | 16.6 | 13 | 4 | 60' | 245 |
| B | 50 | 13.8 | 11 | 3 | 60 | 225 |
| C | 40 | 11 | 9 | 2.2 | 60 | 205 |
| HT100 - 265 | | 220 | 61.5 | 42 | 2900 | 45 | 68 | 230 |
| A | 210 | 58.3 | 39 | 45 | 68 | 225 |
| B | 195 | 54.2 | 33 | 37 | 67 | 215 |
| C | 180 | 50 | 29 | 30 | 66 | 2D5 |
| D | 170 | 47.2 | 25 | 22 | 65 | 195 |
| E | 165 | 45.8 | 20 | 18.5 | 62 | 185 |
| | 100 | 27.8 | 17 | 1450 | 11 | 66 | 265 |
| A | 90 | 25 | 14 | 7.5 | 67 | 245 |
| B | 80 | 22.2 | 11 | 4 | 65 | 225 |
| C | 70 | 19.4 | 8.5 | 3 | 63 | 205 |
Applications:
Flue gas desulfurization systems in power plants: Huatao Pulp Pump is applicable in the flue gas desulfurization systems of power plants, which plays a crucial role in eliminating sulfur dioxide from the flue gas. This pump demonstrates excellent performance in dealing with desulfurization slurry and is highly suitable for such scenarios.
Chemical plants: In chemical plants, the Huatao Pulp Pump can be utilized in a multitude of ways. It can be engaged in the transfer of diverse chemicals and is proficient in handling the complex task of wastewater management.
Pulp and paper mills: Huatao Pulp Pump is well-suited for the transportation of pulp within pulp and paper mills. It exhibits the capacity to manage different pulp consistencies effectively and is thus a prime choice for this particular application.
Mining industry: The Huatao Pulp Pump proves to be a viable option for transferring slurries in the mining industry. It can cope with both abrasive and viscous slurries, making it an excellent fit for this kind of demanding application.
Wastewater treatment plants: Huatao Pulp Pump can be employed in wastewater treatment plants for a variety of purposes. It is capable of transferring wastewater and handling sludge with relative ease.
In summary, Huatao Pulp Pump is a dependable and efficient centrifugal pump designed for desulfurization, which can be adapted to numerous industries. It has the versatility to handle a wide range of fluid types and is especially suitable for applications where the handling of desulfurization slurry is required. Its extended service life and the availability of OEM support render it a worthy and valuable investment for any enterprise.
Advantages:
Excellent sealing performance
Multiple sealing methods: Provide mechanical seals, dynamic seals and packing seals and other sealing methods for users to choose, which can effectively prevent pulp leakage, protect the working environment and reduce material loss.
Reliable sealing technology: Its sealing technology has been strictly tested and verified, with good wear resistance, corrosion resistance and sealing, ensuring a low leakage rate during long-term operation, improving the overall reliability and safety of the pump.
Easy to maintain
Modular design: Some Sulzer pulp pumps adopt modular design, which makes the disassembly and assembly of the pump more convenient and quick, and is convenient for daily inspection, maintenance and replacement of parts, reducing the difficulty and cost of maintenance, reducing equipment downtime, and improving production efficiency.
Good versatility: The standardization and versatility are high, reducing the types and quantities of spare parts, facilitating spare parts management and inventory control for enterprises, and further reducing operating costs.
